The Shimadzu SPD-10Avp UV-Vis detector is a system controller for Shimadzu VP Series HPLC System, allowing the users to command all VP Series components centrally.
The detector conveniently links all VP Series modules via fiber optic interfacing for easy “plug-and play” setup, and is backward compatible with previous Shimadzu systems. Single poin control allows user-friendly operation from the controller’s easy-to-read, menu-driven display screens.
The detector offers the highest in detector sensitivity and lowest noise level available to ensure reliable peak detection over a wide range.
Technical specifications:
Voltage: 220-240 V
Current: A
Power: W
Ambient Temperature Range: 4-352C
Light source: D2 lamp, W lamp
Signal-To-Noise (S/N) Ratio: +/- 0.35 x 10-5 AU
Wavelength repeatability: 0.1 nm
Wavelength range: 190-900 nm
Wavelength accuracy: +/- 1 nm
Wavelength reproducibility: +/- 0.1 nm
Spectral bandwidth: 8 nm
Drift: 2 x 10-4 AU/hour Max. (constant room temp)
Wavelength Scanning: Steps: 1 – 5 nm, in 5 steps (2-5 nm when W lamp is used)
Scan speed: 10 – 50 nm/sec, 5 steps
Time Program: controlled by detector unit itself or by system controller
Outer dimensions (W) x (D) x (H):Â 260 x 420 x 140 mm
