The Alcatel 2012A vacuum pump is an oil-lubricated rotary vane pump with a pumping speed of 11 cfm and a final pressure of 1 x 10-4 Torr. Alcatel 2012 pumps are two-stage mechanical pumps that can be used to create a medium vacuum (up to 10-3 mbar) or in pump assemblies to support a diffusion pump or turbomolecular pump.
Technical specifications:
Voltage: 230 V
Current: 4A
Power: 0.37 kW
Galballast: Yes
Speed: 1430
Pumping speed: 300 L/min
Max. Vacuum: 2×10^-2 mbar
External dimensions (W) x (D) x (H): 200 x 450 x 300 mm
Weight: 23 kg
